Features:
8chs Double 1000Mbps Uplink Port POE Switch
8pcs 10M/100M adaptive POE port + 2pcs 1000M cascades
backplane bandwidth：2Gbps
IEEE802.3at POE Protocol
data and power transmission distance: 100M
POE single port output power: 25.5W
Standard power supply: 150W 48V 3A (built in power supply)
| Specifications | |||
| Model | WDM-PSE1082TG | ||
| Name | 8chs double 1000Mbps Uplink port POE switch | ||
| Connector Type | 8pcs 10M/100M adaptive POE port + 2pcs 1000M cascades | ||
| Network Media | 10BASE-T: Cat3,4,5 UTP(≤100 meter); 100BASE-TX: Cat5 or more UTP (≤100 meter) | ||
| Bandwidth | 2Gbps | ||
| Forwarding Mode | Store-And-Forward Architecture | ||
| Network Protocols | IEEE 802.3i 10BASET; IEEE 802.3u 100BASETX; IEEE 802.3x Flow Control IEEE 802.1af DTE Power via MDI; IEEE 802.3at | ||
| LED Display | System: power supply; Every Port: connecting, POE working status | ||
| Power Supply | 150W, 48V, 3A （internal power supply) | ||
| POE Port Power | 1-8 Port support POE Output, 25.5Watts per port | ||
| Power Consumption | 150W | ||
| Transmission Distance | 100m | ||
| POE Standard | IEEE802.3at | ||
| Working Environment | Working temperature:-20°~ 55°C , Storage temperature: -40°~ 85°C,Working Humidity: 5%~95%, non-condensing | ||
| Package List | |||
| POE Switch | x1 | ||
| AC Adapter | x1 | ||
| User Manual | x1 | ||
