Features:
24chs Full 1000Mbps Double SFP fiber port POE Switch
24PCS 1000M POE Port, 400w power suppply
2PCS 1000M SFP Electrical Port
IEEE802.3at POE Protocol
data and power transmission distance: 100M
backplane bandwidth：52G
| Specifications | |||
| Model | WDM-PSE2024GP | ||
| Name | 24chs full 1000M POE Switcher | ||
| Connector Type | 24pcs 1000M POE Port + 2PCS 1000M SFP Electrical Port | ||
| Network Media | 10BASE-T: Cat3,4,5 UTP(≤100 meter); 100BASE-TX: Cat5 or more UTP (≤100 meter) | ||
| Bandwidth | 52Gbps | ||
| Forwarding Mode | Store-And-Forward Architecture | ||
| Network Protocols | IEEE 802.3i 10BASET; IEEE 802.3u 100BASETX; IEEE 802.3x Flow Control IEEE 802.1af DTE Power via MDI; IEEE 802.3at | ||
| LED Display | System: power supply; Every Port: connecting, POE working status | ||
| Power Consumption | 400W | ||
| Transmission Distance | 100m | ||
| POE Standard | IEEE802.3at | ||
| Working Environment | Working temperature:-20°~ 55°C , Storage temperature: -40°~ 85°C,Working Humidity: 5%~95%, non-condensing | ||
| Package List | |||
| POE Switch | x1 | ||
| AC Adapter | x1 | ||
| User Manual | x1 | ||
