Features:
Support 32CH 5MP unreal-time encoding
Support XVI,AHD, TVI,CVI, CVBS, IP video input
Support VGA maximum 1080P output, HDMI up to 4K output
Support DHCP, FTP, DNS, DDNS, NTP, UPNP, EMAIL, 3G, WIFI, IP search, Alarm center, etc
Support the Onvif protocol
Support WEB, CMS, VMS, MYEYE Platform
Mobile phone remote monitoring (iOS, Android)
Cloud services, P2P, alarm information push to phone
Support for more than twenty languages
> 32ch 4K-N DVR Video Recorder
> Support 1-ch HDMI, 1-ch VGA
> HDMI and VGA simultaneous output
> Up to 4K-N resolution recording
> 2 SATA HDD up to 8 TB
> Support cloud storage
| Specifications | ||
| Product Name | WDM 32CH 4K-N 6 In 1 2HDD Big 1U CCTV Security DVR Digital Video Recorder | |
| Model No. | WDM-DVR6532E-GS | |
| System | ||
| Processor | Hi3531D*2 | |
| Video | ||
| Video compression | H.265+/H.265/H.264 | |
| Encode | 32*4M@8fps(6 in 1): 32*5M@6fps(6 in 1); 32*4K-N @7fps (6 in 1); 4M Default | |
| Decode | 16*4M@8fps(6 in 1): 8*5M@6fps(6 in 1); 8*4K-N @7fps (6 in 1); 4M Default | |
| preview | 32*4M@15fps(6 in 1): 32*5M@12fps(6 in 1); 32*4K-N @15fps (6 in 1); 4M Default | |
| Multi-mode | Analog: 32*4M; 32*5M | |
| Digital Analog conversion: Support | ||
| IP: 32*1080P/16*3M/8*5M | ||
| Playback | 16/8CH | |
| Audio | ||
| Audio compression | G.711A | |
| Management | ||
| Record mode | Manual>Alarm>Motion detection>Timing | |
| Inquire mode | Inquire by Time/Calendar/Event/Channel | |
| Storage mode | HDD Storage, Network Storage | |
| Backup | Network, USB, SATA | |
| Interface | ||
| Video Input | 32*BNC (Support Coaxitron) | |
| HDMI output | 1*HDMI (MAX:4K) | |
| VGA output | 1*VGA (MAX:1080P) | |
| Audio In/Out | 16/1 | |
| Alarm In/Out | 16/4 | |
| Ethernet | 1*10/100Mbps Ethernet port, RJ45 port | |
| PTZ Control | 1*RS485, Support for multiple PTZ protocol | |
| USB | 2*USB2.0 ports | |
| HDD | 2*SATA interface (Up to 6TB) | |
| General | ||
| Power supply | 12V4A | |
| Consumption | <10W (Without HDD) | |
| Working temperature | 0 ℃ - + 55 ℃ | |
| Working humidity | 10% -90% RH | |
| Chassis | 1U | |
